Contact Material: Phosphor Bronze 0.15mm thickness Standard Insulator Material: Nylon 6T, UL 94V-0 Optional insulator material: LCP UL 94V-0 Contact Terminal: Phospho Bronze
Plating
Contact Terminal Underplating: Nickel-plated all over Contact Plating: Gold Flash all over (Standard) Contact Plating Options: Tin all over, 10µ" & 30µ" Gold
Electrical
Voltage Rating: 250V AC/DC Current Rating: 2 AMP Contact Resistance: 20mΩ Max Insulation resistance: 1000MΩ Min Dielectric withstanding voltage: 500V AC for 1 minute between adjacent terminal, no breakdown
Environmental and Processing
Operating Temperature: -40°C to +105°C Solder Temperature: Peak temp 260°C (+/-5°C) Maximum (10 +/-5 seconds)
