Contact Material: Brass Standard Insulator Material: Polyamide Nylon 6T, UL94V-0, Black Optional insulator material: LCP, UL94V-0, Black Contact Terminal: Brass
Plating
(A) Finish: Gold Flash All Over - Under Plate: Nickel 30-50µ” (B) Finish: Selective gold flash contact area/tin on tail - Under Plate: Nickel 50-100µ” (C) Finish: Tin All Over – 80µ” minimum – Under Plate: Nickel 30-50µ” (G&I) Finish: Gold 10µ” (G) or 30µ” (I) on contact area. Tin 100µ” minimum on tail - Under Plate: Nickel 50-100µ”
Electrical
Voltage Rating: 250V AC / DC Current Rating: 2 AMP Contact Resistance: 20mΩ Max Insulation resistance: 1000MΩ Min. Dielectric withstanding voltage: 500V AC for 1 minute between adjacent terminal, no breakdown
Environmental and Processing
Operating Temperature: -40°C to +105°C Solder Temperature: Peak temp 260°C (+/-5°C) Maximum (10 +/-5 seconds)
