Contact Material: Stainless Steel Housing Material: PA9T, Black Contact Terminal: Brass Switch Button: PA9T, Black Cover Shell: Brass
Plating
Contact Plating: Silver Solder Tail: Silver Metallic Shell: Tin
Electrical
Voltage Rating: 12VDC Current Rating: 50mA Contact Resistance: 100mΩ Max Insulation resistance: 100MΩ Min Dielectric withstanding voltage: 250VAC, 1 Min.
Mechanical
Durability: 100,000 Cycles
Environmental and Processing
Operating Temperature: -25°C to +85°C Solder Temperature: Peak temp 260°C (+0/-5°C) Maximum (5 seconds)
