Contact Material: Copper Alloy Standard Insulator Material: LCP, Black, UL 94V-0 Contact Terminal: Copper Alloy Metallic Shell: Stainless steel
Plating
Contact Terminal plating Underplating: 40µ" Min. Nickel all over Contact Plating: Gold flash Solder Area: 80µ" Min. Matte Tin Metallic Shell plating Underplating: 30µ" Min. Nickel all over Solder Area: Gold flash
Electrical
Voltage Rating: 30V DC Current Rating: 0.5A Contact Resistance: 100mΩ Max Insulation resistance: 1000MΩ Min Dielectric withstanding voltage: 500VAC, 1 Min.
Mechanical
Durability: 5,000 Cycles
Environmental and Processing
Operating Temperature: -40°C to +85°C Solder Temperature: Peak temp 260°C (+0/-5°C) Maximum (5 seconds)
