Contact terminal plating Underplating: 60µ" Nickel all over Contact Plating: 3µ" Gold Solder Area: 100µ" Tin Metallic shell plating Underplating: 60µ" Nickel over all
Electrical
Voltage Rating: 100 VAC Current Rating: 0.5A Max Contact Resistance: 100mΩ Max Insulation resistance: 500MΩ Min. (Apply 500 VDC) Dielectric withstanding voltage: Leaking current <1mA (apply 500VAC for 1 min)
Mechanical
Durability: 5,000 cycles Insertion Force: 10N Max Extraction Force: 10N Max
