Housing Material: LCP UL94V-0, Black Contact Terminal: Copper alloy Metallic Shell: Stainless steel SMT Hold Down: Stainless Steel
Plating
Contact terminal plating Underplating: 50µ" Nickel all over Contact Plating: Gold flash Solder Area: Tin Metallic shell plating Solder Area: Front: Gold flash, Rear: Tin
Electrical
Voltage Rating: 100 V DC Current Rating: 0.5A Max Contact Resistance: 100mΩ Max Insulation resistance: 1000MΩ Min. (Apply 500 VDC) Dielectric withstanding voltage: Withstand 500 V AC for 1 min
