Contact terminal plating Underplating: 80µ" Min. nickel all over Contact Plating: Gold Flash Solder Area: Gold flash Metallic shell plating Underplating: 30µ" Nickel all over Solder Area: Gold flash
Electrical
Voltage Rating: 5V AC/DC Current Rating: 0.5A Contact Resistance: 100mΩ Max Insulation resistance: 1000MΩ MIN at 500V DC Dielectric withstanding voltage: 500V AC for 1 minute between adjacent terminal, no breakdown
Mechanical
Durability: 5,000 cycles
Environmental and Processing
Operating Temperature: -25°C to +85°C Solder Temperature: Peak temp 255°C (+5/-0°C) Maximum (5 seconds)
